Description

Dimension-Differentiation by shape
● Square straight tube
G4.5: Length 1470mm, average thickness 3.0mm, top and bottom 3.0mm, left and right 4.0mm
G4.5: Length 1470mm, average thickness 2.0mm
G5: Length 1720mm, top 3.0mm, bottom 3.5mm, left and right 3.0mm average thickness
G6: Length 2470mm, average thickness 3.5mm
G6: Length 2470mm, average thickness 3.0mm

● Curved surface
G4.5: Length 1470mm Thickness: Large end 6.0mm ~ Small end 3.0mm
G6: Length 2520mm Thickness: Large end 5.5mm/3.5mm ~ Small end 2.5mm
G7.5: Length 3120mm Thickness: Large end 6.5mm/3.0mm ~ Small end 3.0mm

The Robot Fork is used with loaders of various generations and process equipment. The Robot-Fork is primarily used to remove and load substrates into process tools or cassettes.
