8-Inch RFID E-Rack Electronic Shelf

The RFID E-Rack electronic shelf is an RFID reading rack specifically designed for 8-inch OPEN BOX. It is compatible with 8-inch Wafer Shipping Box and Wafer Storage Box. It can automatically read RFID and record data for each slot, which can be queried through the human-machine interface.

Operating Environment: Ambient temperature 0-40℃, ambient humidity 35-85% Rha
RFID Specifications: Frequency 134.2KHz, reads TI 134.2KHz Tag
Controller: PC controller, HSMS/RS232 interface
Human-Machine Interface: 21.5-inch or larger display, customizable UI
Indicator Lights:
Red light: RFID reading error
Green light: RFID reading successful
Yellow light: Customizable
Data Storage: FTP server
Operation Instructions:
Place the carrier into the slot — Infrared sensor detects — RFID Reader reads the RFID Tag information:
–If reading is successful, the interface displays the content of the Tag and the green light turns on.
–If reading fails, the interface displays ERROR and the red light turns on

Product Specifications:

● Product Name: RFID E-Rack Electronic Shelf
● Product Dimensions: 1903(D) x 388(W) x 1807(H) mm
● Shelf Space: H385 mm
● Storage Capacity: 25 PCS
● Weight: 120 kg
● Maximum Storage Size: 8-inch OPEN BOX
● Compatible Product Size: 8-inch BOX
● Material: SUS304 Stainless Steel Mirror Finish
